So, to help better explain Keryx's high level and low level layout, I
figured it was imperative we have some diagrams to explain this. Attached
are the three diagrams I currently have laying out the backend of Keryx, the
database structure, and a high level approach to what Keryx is. Take a look,
see if anything is incorrect or needs cleaning up and start sending me some
feedback. :D

Note: The original Dia diagrams and these exported PNG's will be available
in the lp:keryx/devel branch as soon as I get internet access back on my
desktop.

--
Chris Oliver
http://excid3.com

Attachment: ClassDiagram.png
Description: PNG image

Attachment: Database.png
Description: PNG image

Attachment: LibKeryx_ClassDiagram.png
Description: PNG image
